Petzl Paw + Petzl Swivel Opens

$625.00 AUD Inc. GST

Get organised, sleek and strong with this rigging set for your net, teardrop, dance trapeze or hammock. The Petzl Paw and Petzl Swivel Opens make a neat combination for the top of your gear. Buy them as a set and we’ll put it together for you!

SKU: HW-21 Categories: , , Tags: , , , , ,

Description

Petzl Paw: Description
For organizing the belay and creating a system with multiple anchors. Useful in aid setting up mechanical advantage, hoist systems for crane bars and swinging safety systems.
Available in red only.
Design Components
  • 19 mm holes allow the locking sleeves of most carabiners to pass through, enabling the carabiner to be rotated
  • hole design allows ropes or slings to be threaded for direct connection.
  • main attachment hole accepts up to three carabiners
  • the odd number of attachment holes enables the system to be centered and balanced
  • three anchor point holes
  • helps to equalize loads
  • made of forged aluminum for an excellent strength-to-weight ratio
  • durable markings, thanks to the recessed area in the center of the plate
  • Certification(s): CE, NFPA 1983

Strength

  • MBS: 23 kN
  • WLL: 5kN

Technical notice available here

Petzl Swivel Open: Description

Gated swivel with sealed ball bearings

  • Can be attached to a wide range of products (pulleys, lanyards…) because of its large opening.
  • Reduces bulk and weight of component systems.
  • Solves the twisting and tangling problems of ropes and lanyards in different situations:
    – hauling: prevents rope twist when the load turns on itself, thus reducing kinking
    – hauling: avoids the risk of friction between ropes, which improves efficiency
    – progression with a lanyard: avoids twisting and simplifies manipulations
  • Excellent performance and reliability due to maintenance-free sealed ball-bearings
  • Weight: 130 g
  • Certification(s): CE, NFPA 1983 Technical Use, EAC
  • Material(s): aluminum, nylon
  • Color(s): yellow/black

Please Note:

  • The screw is designed to be tightened to 2.5Nm. It should be installed and regularly inspected with a torque wrench.
  • To strengthen the hold of the screw, use Loctite 222 (appropriate for alloy materials). DO NOT put the Loctite on the rubber washer, ONLY on the thread of the screw.
  • The hex key needed for tightening the screw is a standard size. It is no longer supplied with the item (to reduce waste) so expect to have to supply the hex key yourself when assembling.

Technical notice available here
